StarTech.com - StarTech.com 1ft CAT6a Ethernet Cable LSZH
10GbE S/FTP 100W PoE Blue - Patch cable - RJ-45 (M) to RJ-45 (M) - 1 ft - 0.2 in - S/FTP - CAT 5/5e/6/6a - IEEE 802.3bt - snagless, halogen-free, passive, stranded - blue
StarTech.com
NLBL-1F-CAT6A-PATCH
N/A
0065030896375
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | StarTech.com 1ft CAT6a Ethernet Cable LSZH - 10GbE S/FTP 100W PoE Blue - patch cable - 1 ft - blue |
| Type | Patch cable - CAT 5/5e/6/6a - IEEE 802.3bt |
| Technology | S/FTP |
| Wiring Scheme | T568B |
| Shielding Material | Aluminum mylar foil with braid |
| Wires per Cable | 8 wires |
| Features | Snagless, halogen-free, passive cable, stranded, up to 10 Gbps, 100W PoE++ support, pure bare copper conductors, strain relief, test fluke pass, EMI/RFI protection, 50 micron gold-plated connectors, flame retardant, minimized Near-End Crosstalk (NEXT), reduced Return Loss (RL) |
| Length | 1 ft |
| Diameter | 0.2 in |
| Connector | RJ-45 - male |
| Connector (Second End) | RJ-45 - male |
| Color | Blue |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Network Cable Type | Patch cable - CAT 5/5e/6/6a - IEEE 802.3bt |
| Technology | S/FTP |
| Wiring Scheme | T568B |
| Shielding Material | Aluminum mylar foil with braid |
| Jacket Material | Low Smoke Zero Halogen (LSZH) |
| American Wire Gauge (AWG) | 27 |
| Wires per Cable | 8 wires |
| Pairs per Cable | 4 pairs |
| Plated Connector | Gold |
| Features | Snagless, halogen-free, passive cable, stranded, up to 10 Gbps, 100W PoE++ support, pure bare copper conductors, strain relief, test fluke pass, EMI/RFI protection, 50 micron gold-plated connectors, flame retardant, minimized Near-End Crosstalk (NEXT), reduced Return Loss (RL) |
| Length | 1 ft |
| Diameter | 0.2 in |
| Weight | 0.71 oz |
| Color | Blue |
| Manufacturer Warranty | |
| Service & Support | Limited lifetime warranty |
| Miscellaneous | |
| Compliant Standards | TIA/EIA T568B, ANSI/TIA-568.2-D, PoE++, ETL, RoHS, WEEE, IEEE 802.3bt Type 4 - up to 500 MHz |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Connectivity | |
| Connector | RJ-45 - male |
| Connector (Second End) | RJ-45 - male |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 8.7 in |
| Shipping Depth | 7.7 in |
| Shipping Height | 0.3 in |
| Shipping Weight | 1.02 oz |
