Axis Communications - AXIS M55 Series M5526-E
Network surveillance camera - PTZ - dome - outdoor - vandal / weatherproof - color (Day&Night) - 4 MP - 2688 x 1512 - auto iris - audio - LAN 10/100 - H.264, MPEG-4 Part 10, AVC, H.265, MPEG-H Part 2, HEVC, MJPEG - DC 20 - 28 V / PoE Class 3 (pack of 4)
Axis Communications
02769-021
N/A
7331021088399
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | AXIS M55 Series M5526-E - network surveillance camera - dome |
| Device Type | Network surveillance camera - pan / tilt / zoom - dome - outdoor - vandal / weatherproof |
| Packaged Quantity | 4 (specifications are for single item) |
| Audio | Yes: two-way audio capability |
| Dimensions (WxDxH) | 6.5 in x 6.5 in x 5.9 in |
| Weight | 2.2 lbs |
| Color | White, NCS S 1002-B |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night |
| Optical Zoom | 10 x |
| Max Resolution | 2688 x 1512 |
| Frame Rate (max) | 50 frames per second |
| Motion Detection | Yes |
| Optical Sensor Type | PS RGB CMOS - 1/3" - 4 MP |
| Minimum Illumination | 0.2 lux - color - F1.6 - 30 IRE ¦ 0.25 lux - color - F1.6 - 50 IRE ¦ 0.01 lux - B&W - F1.6 - 30 IRE ¦ 0.01 lux - B&W - F1.6 - 50 IRE |
| Focal Length | 4.7 mm - 47 mm |
| Focus Adjustment | Automatic |
| Lens Iris | F/1.6-3.0 - auto iris (P-Iris) |
| Panning Range (degree) | 360 |
| Tilting Range (degree) | 0 to 90 |
| Interfaces | Ethernet 10Base-T/100Base-TX |
| Voltage | DC 20 - 28 V / PoE Class 3 |
| Features | Infrared cut filter, deep learning processing unit (DLPU), Nadir flip, 100 preset positions, control queue, on-screen directional indicator, spot focus, Zipstream technology, Adaptive Bitrate (ABR), Multi-Bitrate (MBR), Variable Bitrate (VBR), low latency mode, video streaming indicator, Forensic WDR, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), 180° image rotation, brightness control, compression, contrast control, day/night threshold, exposure mode, exposure zone, image overlay, polygon privacy mask, saturation control, sharpness control, text overlay, tone mapping, white balance, Lightfinder 2.0 technology, Automatic Gain Control (AGC), network speaker pairing, ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, ONVIF (Profile M) support, Pixel Counter Support, level grid, AXIS Object Analytics, active tampering alarm, Audio Detection, secure keystore, signed video, secure boot, NAS-Ready, TPM 2.0 module, DORI coverage |
| Manufacturer Warranty | 5-year warranty |
| Environmental Parameters (operating) | -4 °F - 122 °F; 15 - 100% RH (condensing) relative humidity |
| General | |
| Packaged Quantity | 4 (specifications are for single item) |
| Device Type | Network surveillance camera |
| Audio Support | Yes: two-way audio capability |
| Audio Formats | LPCM, AAC-LC, G.711, PCM, G.726, ADPCM, OPUS |
| Form Factor | Dome |
| Connectivity Technology | Wired |
| Width | 6.5 in |
| Depth | 6.5 in |
| Height | 5.9 in |
| Weight | 2.2 lbs |
| Localization | United States |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 ¦ Audio line-in/microphone - terminal block |
| Supported Memory Cards | SD Memory Card, SDXC Memory Card, SDHC Memory Card |
| Encryption Algorithm | EAP-TLS, 256-bit AES-XTS, PEAP, MSCHAPv2, TLS 1.2, TLS 1.3 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | Bayonet adapter, terminal block connectors, connector guard, owner authentication key |
| Compliant Standards | IEEE 802.1x, IEEE 802.1ar, CSA, UL/cUL, BIS, UKCA, KC, EAC, VCCI, RCM, EN 55035, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, AS/NZS CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, KS C 9835, KS C 9832 Class A, FCC Part 15 B Class A, CAN/CSA C22.2 No. 62368-1 Third Edition, IEC/EN/UL 62368-1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, IEC 60068-2-6, IEC 60068-2-27, NIST SP500-267, ETSI EN 303 645, EAL 6+, IEEE 802.1ae, X.509, IEEE 802.3at, IEEE 802.3af, PVC-free, BFR-free, CFR free, JEDEC, ECA, EN 63000:2018, REACH 1907/2006/CE, RoHS 2011/65/EU |
| Color | White, NCS S 1002-B |
| Power | |
| Power Requirements | DC 20 - 28 V / PoE Class 3 |
| Power Device | 4.2 Watt |
| Software / System Requirements | |
| Software Included | AXIS Object Analytics, AXIS Video Motion Detection |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 122 °F |
| Relative Humidity (operating) | 15 - 100% RH (condensing) |
| Camera | |
| Type | Color - Day&Night - pan / tilt / zoom - outdoor - vandal / weatherproof |
| Digital Video Format | H.264, MPEG-4 Part 10, AVC, H.265, MPEG-H Part 2, HEVC, MJPEG |
| Max Digital Video Resolution | 2688 x 1512 |
| Motion Detection | Yes |
| Digital Zoom | 12 |
| Exposure Range | 0.2 sec - 1/27000 sec |
| Minimum Illumination | 0.2 lux - color - F1.6 - 30 IRE ¦ 0.25 lux - color - F1.6 - 50 IRE ¦ 0.01 lux - B&W - F1.6 - 30 IRE ¦ 0.01 lux - B&W - F1.6 - 50 IRE |
| Digital Video Capture Resolution | 2688 x 1512, 1920 x 1280, 1600 x 1200, 320 x 180, 240 x 160, 160 x 120 |
| Frame Rate (max) | 50 frames per second |
| RAM | 1 GB |
| Flash Memory | 8 GB |
| Features | Infrared cut filter, deep learning processing unit (DLPU), Nadir flip, 100 preset positions, control queue, on-screen directional indicator, spot focus, Zipstream technology, Adaptive Bitrate (ABR), Multi-Bitrate (MBR), Variable Bitrate (VBR), low latency mode, video streaming indicator, Forensic WDR, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), 180° image rotation, brightness control, compression, contrast control, day/night threshold, exposure mode, exposure zone, image overlay, polygon privacy mask, saturation control, sharpness control, text overlay, tone mapping, white balance, Lightfinder 2.0 technology, Automatic Gain Control (AGC), network speaker pairing, ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, ONVIF (Profile M) support, Pixel Counter Support, level grid, AXIS Object Analytics, active tampering alarm, Audio Detection, secure keystore, signed video, secure boot, NAS-Ready, TPM 2.0 module, DORI coverage |
| Lens Construction | |
| Optical Zoom | 10 x |
| Focal Length | 4.7 mm - 47 mm |
| Lens Iris | F/1.6-3.0 auto iris (P-Iris) |
| Focus Adjustment | Automatic |
| Horizontal Field of View (degree) | 6.5 - 59.1 |
| Vertical Field of View (degree) | 3.67 - 35 |
| Image Sensor | |
| Type | 4 MP PS RGB CMOS 1/3" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | IPv4, IPv6, USGv6, ICMP, HTTP, HTTPS, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, NTS, RTSP, RTP, SRTP, RTSPS, TCP/IP, UDP/IP, IGMP, RTCP, DHCP, ARP, SSH, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Panning | |
| Range (degree) | 360 |
| Speed (degree/sec) | Up to 150 |
| Tilting | |
| Range (degree) | 0 to 90 |
| Speed (degree/sec) | Up to 150 |
