Minuteman UPS - Minuteman EXR Series EXR1500RT2U
UPS (rack-mountable / external) - AC 120 V - 1350 Watt - 1500 VA - 1-phase - RS-232, USB - output connectors: 8 - 2U - 19" - for Minuteman BP36CRTXL, BP36V48RTEXL
Product Description
Additional Details
- Special Delivery: None
What's Included
| Main Specifications | |
|---|---|
| Product Description | Minuteman EXR Series EXR1500RT2U - UPS - 1350 Watt - 1500 VA |
| Device Type | UPS - rack-mountable / external |
| Rack Size | 19" - 2U |
| Weight | 42.99 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V |
| Power Capacity | 1350 Watt / 1500 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 8 x power NEMA 5-15R |
| Battery | Lead acid |
| Run Time (Up To) | 2.5 min at full load |
| Networking | RS-232, USB |
| Remote Management Protocol | SNMP |
| Dimensions (WxDxH) | 19 in x 17.3 in x 3.5 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 3-year warranty |
| Designed For | Minuteman BP36CRTXL, BP36V48RTEXL |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Rack Size | 19" |
| Expansion / Connectivity | |
| Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ 1 x EPO (emergency power off) |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - electrical components and functions - 3 years ¦ Limited warranty - batteries - 3 years |
| Miscellaneous | |
| Cables Included | Power cable 10 ft |
| Rack Mounting Kit | Included |
| Equipment Protection Value | 100000 US Dollars |
| Features | Emergency power off, LCD display, internal bypass, hot-swappable batteries, battery monitoring |
| Compliant Standards | FCC Class B certified, NOM, cULus, RoHS2, Directive 2011/65/EU, UL 1778 5th edition, CSA C22.2 No. 107.3.14, Directive 2015/863/EU |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Remote Management Protocol | SNMP |
| Software / System Requirements | |
| Software Included | Minuteman SentryHD |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Battery | |
| Technology | Lead acid |
| Run Time (Up To) | 9 min at half load ¦ 2.5 min at full load |
| Recharge Time | 8 hours |
| Features | Maintenance free, sealed, spill-proof, valve-regulated, hot-swappable |
| Power Device | |
| UPS Technology | Line interactive |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 80 - 164 V |
| Input Wiring | 1-phase |
| Frequency Required | 50/60 Hz ± 6Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 8 x power NEMA 5-15R |
| Output Voltage | AC 120 V |
| Power Capacity | 1350 Watt / 1500 VA |
| Dataline Surge Protection | Network - RJ-45 - 1 input line / 1 output line |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 1000 Joules |
| Circuit Protection | Circuit breaker |
| Power Factor (PF) | 0.9 |
| Dimensions & Weight | |
| Width | 19 in |
| Depth | 17.3 in |
| Height | 3.5 in |
| Weight | 42.99 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 21.9 in |
| Shipping Depth | 23.7 in |
| Shipping Height | 9.8 in |
| Shipping Weight | 52.69 lbs |
| Compatibility Information | |
| Designed For | Minuteman BP36CRTXL, BP36V48RTEXL |
| Sustainability Information | |
| ENERGY STAR | Yes |
