StarTech.com - StarTech.com 3-Bay Hot Swap Backplane for 3.5in SAS II/SATA III
6 Gbps HDD - Aluminum Trayless Mobile Rack Backplane (HSB3SATSASBA) - Storage mobile rack - 2.5" - black - for P/N: 25SAT35HDD, PEXMSATA3422, PEXMSATA343
StarTech.com
HSB3SATSASBA
N/A
0650308552970
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | StarTech.com 3-Bay Hot Swap Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD - Aluminum Trayless Mobile Rack Backplane (HSB3SATSASBA) - storage mobile rack |
| Device Type | Storage mobile rack |
| Color | Black |
| Expansion Bays | 3 x hot-swap - 3.5" |
| Compatible Bay | 2 5.25" |
| Hard Drive Form Factor Compatibility | 2.5" |
| Supported Interface | SATA-600 |
| Drive Connector | 29 pin internal SAS (SFF-8482) |
| Features | Data indicator, power indicator |
| Product Material | Aluminum |
| Dimensions (WxDxH) | 5.7 in x 7.6 in x 4.3 in |
| Weight | 2.65 lbs |
| Manufacturer Warranty | 2-year warranty |
| Designed For | P/N: 25SAT35HDD, PEXMSATA3422, PEXMSATA343 |
| General | |
| Device Type | Storage mobile rack |
| Hard Drive Form Factor Compatibility | 2.5" |
| Product Material | Aluminum |
| Color | Black |
| Supported Interface | SATA-600 |
| Features | Data indicator, power indicator |
| Expansion / Connectivity | |
| Bays | 3 x hot-swap - 3.5" |
| Interfaces | 3 x SATA 6Gb/s - 29 pin internal SAS (SFF-8482) |
| Connections | 3 - 7 pin Serial ATA ¦ 2 - 15 pin Serial ATA power |
| Compatible Bay | 2 x external 5.25" |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 3 x Serial ATA cable - 1.5 ft |
| Mounting Kit | Included |
| Compliant Standards | FCC, RoHS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 5 - 85% |
| Storage Controller | |
| Processor | No CPU |
| Dimensions & Weight | |
| Width | 5.7 in |
| Depth | 7.6 in |
| Height | 4.3 in |
| Weight | 2.65 lbs |
| Compatibility Information | |
| Designed For | P/N: 25SAT35HDD, PEXMSATA3422, PEXMSATA343 |
